Induction Motor Configuration

Configure induction motor system parameters

  • Library:
  • Motor Control Blockset HDL Support / Electrical Systems / Motors

Description

The Induction Motor Configuration block generates the configuration signal for an induction machine/motor. This signal can be used to update parameters of induction motor blocks that support FPGA deployment, for example, Induction Motor HDL.

Ports

Output

expand all

Configuration signal for induction machine/motor.

Data Types: single | double | fixed point

Parameters

expand all

Block Options

This table summarizes the port configurations.

Port ConfigurationCreates Input PortCreates Output Port

Torque

LdTrq

MtrSpd

Speed

Spd

MtrTrq

Integration sample time for discrete simulation, in s.

Parameters

Motor pole pairs, P.

Stator resistance, Rs, in ohm.

Stator leakage inductance, Lls, in H.

Rotor resistance, Rr, in ohm.

Rotor leakage inductance, Llr, in H.

Magnetizing inductance, Lm, in H.

Physical inertia of the motor, J, in kg.m^2.

Viscous damping of the motor, F, in N·m/(rad/s).

Static friction of the motor, Tf, in N·m.
