propagateOrbit
Calculate position and velocity in International Celestial Reference Frame (ICRF)
Since R2023b
Syntax
Description
[
calculates the positions and velocities in the International Celestial Reference Frame
(ICRF) corresponding to the time specified by positions
,velocities
] = propagateOrbit(time
,tleStruct
)time
using the
two-line-element (TLE) data defined by tleStruct
.
[
calculates the positions and velocities using specified orbital elements to define epoch
states. The function assumes that the epoch is the current Universal Time Coordinated (UTC)
date and time and is the first element in the positions
,velocities
] = propagateOrbit(time
,a
,ecc
,incl
,RAAN
,argp
,nu
)time
argument.
[
calculates the positions and velocities at the epoch defined by positions
,velocities
] = propagateOrbit(time
,rEpoch
,vEpoch
)rEpoch
and vEpoch
. The function assumes that the epoch is the current UTC date
and time and is the first element in the time
argument.
[
calculates the positions and velocities using one or more name-value arguments.positions
,velocities
] = propagateOrbit(___,time
,Name=Value
)
Examples
Read Data from TLE File and Calculate Position and Velocity from Data
Read data from the TLE file 'leoSatelliteConstellation.tle'
and calculate the position and velocity from the TLE structure, tleStruct
.
Read the data from the TLE file 'leoSatelliteConstellation.tle'
, which is on the MATLAB® path and provided with Aerospace Toolbox.
tleStruct = tleread('leoSatelliteConstellation.tle')
tleStruct=40×1 struct array with fields:
Name
SatelliteCatalogNumber
Epoch
BStar
RightAscensionOfAscendingNode
Eccentricity
Inclination
ArgumentOfPeriapsis
MeanAnomaly
MeanMotion
Calculate the position and velocity corresponding to the input time using the TLE data defined in tleStruct
.
[r,v] = propagateOrbit(datetime(2022, 1, 3, 12, 0, 0),tleStruct);
Input Arguments
time
— Julian dates or datetime
1-by-m vector | m-by-1 vector
Julian dates or datetime
, specified as a 1-by-m
vector or m-by-1 vector of datetime
objects or
doubles. time
must be strictly increasing.
When you specify a datetime
object whose
TimeZone
property is empty, propagateOrbit
assumes that the datetime
object time zone is UTC.
Example: datetime(2023,6,16)
Example: juliandate(2023,6,16)
Data Types: double
a
— Semimajor axes
numSc-element vector | scalar
Semimajor axes, specified as a numSc-element vector or scalar, in
meters. If all spacecraft have the same semimajor axis, you can specify
a
as a scalar. numSc is the number of
spacecraft.
Example: 10000000
Example: [8000000 10000000]
Data Types: double
ecc
— Orbit eccentricity
numSc-element vector | scalar
Orbit eccentricity (deviation of orbital curve from circular), specified as an
numSc-element vector or scalar. If all spacecraft have the same
eccentricity, you can specify ecc
as a scalar.
numSc is the number of spacecraft.
Example: 0.1
Example: [0.1 0.2]
incl
— Inclination
numSc-element vector | scalar
Inclination, vertical tilt of the ellipse with respect to the ICRF xy plane measured at the ascending node, specified as a numSc-element vector or scalar. numSc is the number of spacecraft.
Example: 10
Example: [20 30]
RAAN
— Right ascension of ascending node (RAAN)
numSc-element vector | scalar
Right ascension of ascending node (RAAN), specified as a
numSc-element vector or scalar in degrees. If all spacecraft have the
same right ascension of ascending node, you can specify RAAN
as a
scalar. numSc is the number of spacecraft.
Example: 10
Example:
[20 30]
, if there are two spacecraft
argp
— Argument of periapsis
numSc-element vector | scalar
Argument of periapsis, the angle from orbit ascending node to periapsis (closest
point of orbit to the central body), specified as a numSc-element
vector or a scalar. If all spacecraft have the same argument of periapsis, you can
specify RAAN
as a scalar.numSc is the number of
spacecraft.
Example: 10
Example: [20 30]
, if there are two spacecraft
nu
— True anomaly
numSc-element vector | scalar
True anomaly, the angle between periapsis and initial position of spacecraft,
specified as a numSc-element vector or scalar. If all spacecraft have
the same argument of periapsis, you can specify nu
as a scalar.
numSc is the number of spacecraft.
Example: 10
Example: [20 30]
, if there are two spacecraft
rEpoch
— Position at epoch
3-by-1 vector | 3-by-numSc matrix
Position at epoch, specified as a 3-by-1 vector or 3-by-numSc
matrix. If all spacecraft have the same initial position at epoch, you can specify
rEpoch
as a 3-element vector. numSc is the
number of spacecraft.
Example: [10000000;1000;2000]
Example: [10000000 12000000;1000 2000;2000 4000]
, if there are two
spacecraft
Dependencies
rEpoch
and the corresponding vEpoch
vectors cannot be parallel.
vEpoch
— Velocity at epoch
3-by-1 vector | 3-by-numSc matrix
Velocity at epoch, specified as a 3-by-1 vector or 3-by-numSc
matrix. If all spacecraft have the same initial velocity at epoch, you can specify
vEpoch
as a 3-element vector. numSc is the
number of spacecraft.
Example: [0;8000;0]
Example: [0 100;8000 9000;200 300]
, if there are two
spacecraft
Dependencies
vEpoch
and the corresponding rEpoch
vectors cannot be parallel.
tleStruct
— TLE structures
numSc-element vector
TLE structures representing TLE data, specified as an
numSc-element vector. numSc is the number of
spacecraft. To create the TLE structure file, consider using tleread
.
For more information on TLE-file structures, see Two Line Element (TLE) Files.
Example: tleread("leoSatelliteConstellation.tle")
Data Types: string
Name-Value Arguments
Specify optional pairs of arguments as
Name1=Value1,...,NameN=ValueN
, where Name
is
the argument name and Value
is the corresponding value.
Name-value arguments must appear after other arguments, but the order of the
pairs does not matter.
Before R2021a, use commas to separate each name and value, and enclose
Name
in quotes.
Example: PropModel="two-body-keplerian"
specifies
two-body-keplerian
as the propagation method.
Epoch
— Epoch
first value of time
argument (default) | scalar
Epoch, specified as a scalar datetime
, specified as a
double.
When you specify a datetime
object whose
TimeZone
property is empty, the
propagateOrbit
function assumes that the
datetime
object time zone is UTC.
Example: datetime(2023,6,19)
Dependencies
When the epoch states are specified using tleStruct
, do not
specify this name-value argument.
Data Types: double
PropModel
— Orbital state propagation method
"general-perturbations"
(default) | "two-body-keplerian"
| "sgp4"
| "sdp4"
Orbital state propagation method, specified as one of these values:
"general-perturbations"
—"sgp4"
or"sdp4"
, depending on orbital period. When the orbital period corresponding to the epoch states is less than 225 minutes, the propagation model is"sgp4"
. Otherwise, it is"sdp4"
."two-body-keplerian"
— Two-body Keplerian orbit propagator."sgp4"
— Simplified General Perturbations-4 orbit propagator."sdp4"
— Simplified Deep-Space Perturbations-4 orbit propagator.
Example: PropModel="two-body-keplerian"
Data Types: char
| string
BStar
— Aerodynamic drag term
0 (default) | numSc-element vector | scalar
Aerodynamic drag term, specified as a numSc-element vector or
scalar. If all spacecraft use the same Bstar
value, you can
specify this argument as a scalar. numSc is the number of
spacecraft.
Example: BStar=0
Example: BStar=[0.0001 0.0002]
, if there are two
spacecraft
Dependencies
propagateOrbit
uses this value when:
Data Types: double
InputCoordinateFrame
— Input coordinate frame of rEpoch
and vEpoch
"icrf"
(default) | "fixed-frame"
| "geographic"
Input coordinate frame of rEpoch
and vEpoch
,
specified as one of these values:
"icrf"
—rEpoch
andvEpoch
are defined in the ICRF in meters and m/s respectively."fixed-frame"
—rEpoch
andvEpoch
are defined in the Earth-centered Earth-fixed (ECEF) frame in m and m/s respectively."geographic"
—rEpoch
is defined as latitude (degrees), longitude (degrees), and altitude (meters).vEpoch
is defined in the fixed-frame velocity represented in the North-East-Down (NED) frame defined byrEpoch
.
Example: InputCoordinateFrame="fixed-frame"
Data Types: char
| string
OutputCoordinateFrame
— Output coordinate frame of posititions
and velocities
"icrf"
(default) | "fixed-frame"
| "geographic"
Output coordinate frame of output positions
and
velocities
, specified as one of these values:
"icrf"
—positions
andvelocities
are defined in the ICRF in m and m/s respectively."fixed-frame"
—positions
andvelocities
are defined in the Earth-centered Earth-fixed (ECEF) frame in m and m/s respectively."geographic"
—positions
is defined as latitude (degrees), longitude (degrees), and altitude (meters).velocities
is defined in the fixed-frame velocity represented in the North-East-Down (NED) frame defined byrEpoch
.
Example: OutputCoordinateFrame="geographic"
Data Types: char
| string
Output Arguments
positions
— Positions
3-by-m-by-numSc array
Positions, returned as a 3-by-m-by-numSc array. m is the number of time samples. numSc is the number of spacecraft.
velocities
— Velocities
3-by-m-by-numSc array
Velocities, returned as a 3-by-m-by-numSc array. m is the number of time samples. numSc is the number of spacecraft.
Version History
Introduced in R2023b
