dsp.MatrixViewer

Visualize matrix data

Description

The dsp.MatrixViewer visualizes matrix data by mapping the matrix elements to a specified range of colors.

To visualize matrix data in the Matrix Viewer:

1. Create the dsp.MatrixViewer object and set its properties.

2. Call the object with arguments, as if it were a function.

To learn more about how System objects work, see What Are System Objects?

Zoom and Pan

To scale the plot axes, you can use the scroll button on your mouse to zoom in/out of the plot and CTRL+Click and drag to pan around the plot. Additionally, you can use the buttons that appear when you hover over the upper right corner of the plot window.

• — Autoscale the axes to fit the data.

• — Zoom in to the plot.

• — Pan around the axes.

Cursor Measurements

Activate cursor measurements by hovering over the matrix viewer and selecting the cursor button .

Two horizontal and two vertical cursors appear on the plot. A dialog box shows the difference between the two intersection points. Hovering over an intersection point shows the value at that intersection point. Move the cursors by clicking and dragging the cursor lines or the intersection points to your desired location. Additionally, you can Alt+Click and drag the cursor dialog box to move the cursors while keeping the distance between the cursor lines constant.

Creation

Syntax

scope = dsp.MatrixViewer

scope = dsp.MatrixViewer(Name,Value)

Description

scope = dsp.MatrixViewer creates a Matrix Viewer System object™, scope.

scope = dsp.MatrixViewer(Name,Value) sets properties using one or more name-value pairs. Enclose each property name in single quotes. For example, scope = dsp.MatrixViewer("AxisOrigin","Lower left corner")

Properties

Unless otherwise indicated, properties are nontunable, which means you cannot change their values after calling the object. Objects lock when you call them, and the release function unlocks them.

If a property is tunable, you can change its value at any time.

For more information on changing property values, see System Design in MATLAB Using System Objects.

Matrix Information

XDataMode — x-axis numbering mode

"Offset and resolution" (default) | "Custom"

Specify the x-axis numbering mode.

• "Offset and resolution" – Compute the x-axis data points from the XResolution and XOffset properties.

• "Custom" – Compute the x-axis data points using the CustomXData property.

Data Types: char | string

YDataMode — y-axis numbering mode

"Offset and resolution" (default) | "Span and resolution" | "Custom"

Specify the y-axis numbering mode:

• "Span and resolution" – Compute the y-axis data points from the YSpan and YResolution properties.

• "Offset and resolution" – Compute the y-axis data points from the YResolution and YOffset properties.

• "Custom" – Compute the y-axis data points using the CustomYData property.

Data Types: char | string

CustomXData — Custom data values for x-axis

[1 numberOfColumns] (default) | [min max] | monotonically increasing numeric vector

Specify custom values for the x-axis using a two-element numeric vector or a numeric vector with a finite number of elements.

If you specify a two-element vector, the numbers are used as the min and max values of the x-axis. If you specify a vector with more than two elements, the values must be monotonically increasing and the scope uses the first and last values of the vector as the minimum and maximum values, respectively. If you do not specify x-axis data limits, the scope uses the number of input columns as the maximum x-axis value.

Example: [5 156]

Tunable: Yes

Dependency

To enable this property, you must set XDataMode to "Custom".

Data Types: single | double | int8 | int16 | int32 | int64 | uint8 | uint16 | uint32 | uint64

CustomYData — Custom data values for y-axis

[1 numberOfRows] (default) | [min max] | monotonically increasing numeric vector

Specify custom values for the y-axis using a two-element numeric vector or a numeric vector with a finite number of elements.

If you specify a two-element vector, the numbers are used as the min and max values of the y-axis. If you specify a vector with more than two elements, the values must be monotonically increasing and the scope uses the first and last values of the vector as minimum and maximum values, respectively. If you do not specify y-axis data limits, the scope uses the number of input rows as the maximum y-axis value.

Example: [-130 10]

Tunable: Yes

Dependency

To enable this property, you must set YDataMode to "Custom".

Data Types: single | double | int8 | int16 | int32 | int64 | uint8 | uint16 | uint32 | uint64

XOffset — Display offset of x-axis

0 (default) | scalar

Specify the offset to display on the x-axis as a scalar.

Tunable: Yes

Dependency

To enable this property, you must set XDataMode to "Offset and resolution".

Data Types: single | double | int8 | int16 | int32 | int64 | uint8 | uint16 | uint32 | uint64

XResolution — Spacing of x-axis

1 (default) | scalar

Specify the spacing of values along the x-axis as a scalar.

Tunable: Yes

Dependency

To enable this property, you must set XDataMode to "Offset and resolution".

Data Types: single | double | int8 | int16 | int32 | int64 | uint8 | uint16 | uint32 | uint64

YOffset — Display offset of y-axis

0 (default) | scalar

Specify the offset to display on the y-axis as a scalar.

Tunable: No

Dependency

To enable this property, you must set YDataMode to "Offset and resolution".

Data Types: single | double | int8 | int16 | int32 | int64 | uint8 | uint16 | uint32 | uint64

YResolution — Spacing of y-axis

1 (default) | scalar

Specify the spacing of values along the y-axis as a scalar.

Tunable: No

Dependency

To enable this property, you must set YDataMode to "Offset and resolution" or "Span and resolution".

Data Types: single | double | int8 | int16 | int32 | int64 | uint8 | uint16 | uint32 | uint64

YSpan — Span of y-axis

100 (default) | positive scalar

Specify the span of values along the y-axis as a scalar.

Tunable: No

Dependency

To enable this property, you must set YDataMode to "Span and resolution".

Data Types: single | double | int8 | int16 | int32 | int64 | uint8 | uint16 | uint32 | uint64

Visualization

Name — Window name

"Matrix Viewer" (default) | character vector | string scalar

Specify the name of the scope. This name appears as the title of the scope's figure window. To specify the title of plot, use the Title property.

Data Types: char | string

AxisOrigin — Starting location of plot

"Upper left corner" (default) | "Lower left corner"

Specify the starting location of the plot. If you specify "Upper left corner", the plot starts in the top left corner of the axes and continues down.

Data Types: char | string

Position — Scope window position in pixels

screen center (default) | [left bottom width height]

Specify, in pixels, the size and location of the scope window as a four-element vector of the form [left bottom width height]. By default, the scope window appears in the center of your screen with a width of 410 pixels and height of 300 pixels. The default values for this property may change depending on your screen resolution.

Title — Display title

"" (default) | character vector | string scalar

Specify the title of the plot as a character vector or string. By default, there is no title.

Tunable: Yes

Data Types: char | string

XLabel — x-axis label

"" (default) | character vector | string

Specify the text for the scope to display below the x-axis. By default, the axes is unlabeled.

Tunable: Yes

Data Types: char | string

YLabel — y-axis label

"" (default) | character vector | string

Specify the text for the scope to display to the left of the y-axis. By default, the axes is unlabeled.

Tunable: Yes

Data Types: char | string

ColorBarLabel — Color bar label

"" (default) | character vector | string

Specify the text for the scope to display next to the color bar. By default, the color bar is unlabeled.

Tunable: Yes

Data Types: char | string

Colormap — Color scheme

"parula" (default) | colormap name | three-column matrix of RGB triplets

Color scheme for the colormap, specified as a predefined colormap name or a three-column matrix of RGB triplets.

For a list of acceptable colormap names, see map.

To use a custom colormap, specify a three-column matrix of RGB triplets. You can create the RGB matrix yourself, or you can call a predefined colormap function, such as colormap, to create the matrix.

Data Types: single | double | int8 | int16 | int32 | int64 | uint8 | uint16 | uint32 | uint64 | char | string

ColorLimits — Color bar limits

minimum and maximum matrix values (default) | two-element numeric vector [min max]

Specify the color bar limits as a two-element numeric vector [min max]. By default, limits are set as the minimum and maximum values of the input matrix.

Example: [1 80]

Tunable: Yes

Data Types: single | double | int8 | int16 | int32 | int64 | uint8 | uint16 | uint32 | uint64

ColorBarLocation — Color bar location

"eastoutside" (default) | "northoutside" | "southoutside" | "westoutside"

Location of the color bar relative to the axes.

Tunable: Yes

Data Types: char | string

ShowColorBar — Color bar visibility

true (default) | false

Set this property to false to hide the color bar on the plot.

ShowGrid — Grid visibility

true (default) | false

Set this property to false to hide grid lines on the plot.

Tunable: Yes

ShowTicks — Axes tick visibility

true (default) | false

Set this property to false to hide the ticks on the x-axis and y-axis.

Usage

Syntax

scope(matrix)

Description

scope(matrix) displays the matrix by mapping matrix element values to a range of colors.

Input Arguments

matrix — Matrix to visualize

n-by-m numeric matrix

Specify an n-by-m numeric matrix to visualize.

Example: scope(rand(3,5))

Data Types: single | double | int8 | int16 | int32 | int64 | uint8 | uint16 | uint32 | uint64 | logical

Object Functions

To use an object function, specify the System object as the first input argument. For example, to release system resources of a System object named obj, use this syntax:

release(obj)

Specific to dsp.MatrixViewer

setCursorDataLabels

Customize data labels for cursor measurements

Specific to Scopes

show	Display scope window
hide	Hide scope window
isVisible	Determine visibility of scope

Common to All System Objects

step	Run System object algorithm
release	Release resources and allow changes to System object property values and input characteristics
reset	Reset internal states of System object

Examples

Generate Spectrogram with dsp.MatrixViewer

This example shows how to create a spectrogram of a quadratic chirp with the dsp.MatrixViewer System object.

Set up the sample rate and a chirp signal.

Fs = 233e3;
frameSize = 20e3;
chirp = dsp.Chirp("SampleRate",Fs,"SamplesPerFrame",frameSize,...
  "InitialFrequency",11e3,"TargetFrequency",11e3+55e3,...
  "Type","Quadratic");

Create a dsp.MatrixViewer scope. Set the axis labels, select a colormap, and set the limits of the colormap.

scope = dsp.MatrixViewer(...
    "ColorBarLabel","Power/Frequency (dB/Hz)",...
    "XLabel","Frequency (Hz)",...
    "YLabel","Time (secs)",...
    "Colormap","hsv",...
    "ColorLimits",[-100,-30]);

Visualize the spectrogram of the chirp signal in the scope.

for idx = 1:50
    y = chirp() + 0.05*randn(frameSize,1);
    [~,~,~,Ps] = spectrogram(y,128,120,128,1e3);
    val = 10*log10(abs(Ps)'+eps);
    scope(val);
end
