Get Started with Embedded Coder Support Package for Renesas RH850 Microcontrollers

Install hardware support package and identify supported hardware and software requirement

Install Embedded Coder® software and third-party software such as C Compiler for RH850 (CC-RH), AUTOSAR RH850/U2Ax MCAL, AUTOSAR RH850/U2Ax MCAL Patch, and Renesas Flash Programmer (optional).

With this software installed, you can set up your model to use the support package and set up communications with your target hardware.

Topics

MCAL Tutorials

Configuring MCAL Modules Using DaVinci

configure AUTOSAR MCAL modules using the DaVinci Configurator and generate validated C code for use in embedded applications.

Getting Started with ADC Using MCAL

concepts, configuration model, and usage patterns of the ADC peripheral in MCAL-based workflows.

Getting Started With DIO Using MCAL

Digital Input/Output (DIO) concepts in AUTOSAR MCAL and understand how digital pins are modeled, configured, and accessed in MCAL-based workflows.

Getting Started with RH850 TSG3

Get introduced to the RH850 TSG3 Motor Control Timer and understand its capabilities, use cases, and role in Simulink-based motor control and power-electronics workflows.

Featured Examples

Getting Started with MCAL DIO Blocks on Renesas RH850 Microcontrollers

Getting Started with MCAL DIO Blocks on Renesas RH850 Microcontrollers

Control a digital output on a Renesas RH850/U2A16 Microcontroller using the AUTOSAR MCAL DIO Channel Write block in Simulink. The example uses an onboard LED to demonstrate how MCAL DIO configuration and model-based design work together to generate, deploy, and run the model on RH850 hardware to drive an LED.
