Serial Link Design

Design high speed serial links such as PCIe, USB, and Ethernet

The Serial Link Designer app provides a dedicated system-level design and analysis environment for multi-gigabit serial links. Capture your serial link designs graphically and experiment with different physical layout and equalization strategies to predict how design alternatives affect operating margins and the bit error rate (BER) of the link. Use network characterization to model the behavior of the unequalized analog network. This enables quick evaluation of the analog channel design for different trade-offs. Predict the end-to-end behavior of the link using SerDes equalization techniques and clock recovery models obtained by statistical and time-domain analysis. Determine the effect of aggressor signals on overall BER of the channel using crosstalk analysis.

Use the Serial Link Designer app to configure high speed serial links. Set simulation parameters, specify corner conditions, and define stimulus patterns. Setup pre-layout analysis to run SPICE, network characterization, statistical and time domain simulations to analyze your custom serial links. View and interpret the results using the Signal Integrity Viewer app. You can also set up and analyze the post-layout PCB database of your serial link design if you have a license for RF PCB Toolbox™. You can modify the stackup and padstack models and customize vias and see how the changes impact your design.

Apps

Serial Link DesignerAnalyze PCB designs for serial link applications
Signal Integrity ViewerView the signal integrity results of Serial Link Designer or Parallel Link Designer app

Topics

Configure Serial Link Projects

Simulation Parameters Used in Serial Link Design

Set parameters to control SPICE simulation and statistical, time domain, and waveform analysis.

Specify Corner Conditions in Serial Link Design

Specify process corners and etch corners to simulate in serial link project.

Stimulus Patterns in Serial Link Design

Define stimulus patterns for time domain analysis in serial link project.

Model Jitter and Noise While Designing Serial Link

Add TX clock jitter, RX clock jitter, RX clock recovery jitter, and noise.

Pre-Layout Analysis

Pre-Layout Analysis of Serial Link

Learn the basics of pre-layout analysis.

Customize Serial Link Project for Pre-Layout Analysis

Edit transmission line models, designators, S-parameters, and IBIS files to customize pre-layout analysis.

Results of Pre-Layout Analysis in Serial Link

View, interpret, and debug the pre-layout analysis results.

Run Parallel Simulations in Signal Integrity Toolbox

Reduce the time required to run a complete set of simulations by running the simulations in parallel with Parallel Computing Toolbox™.

Post-Layout Verification (Requires RF PCB Toolbox)

Post-Layout Verification of Serial Link

Verify system-level SI and timing margins of PCB design databases.

Stackup and Extraction Control in Serial link Project

Edit stackups and control padstack models.

Via and Stackup Management in Serial Link Project

Manage vias and stackups using Stackup Editor and PadStack Editor.

Featured Examples
