simulateFrequencyResponse

Simulate circuit in frequency domain

Since R2025a

Syntax

[realImpedance,imaginaryImpedance] = simulateFrequencyResponse(circuitModel,frequency)

Description

[realImpedance,imaginaryImpedance] = simulateFrequencyResponse(circuitModel,frequency) simulates the equivalent circuit model, circuitModel, in the frequency domain and returns the real and imaginary impedance.

Examples

Simulate Electrochemical Impedance Spectroscopy Models in Frequency Domain

This example shows how to simulate two different electrochemical impedance spectroscopy (EIS) models in the frequency domain by using the simulateFrequencyResponse function.

Create a fractional-order equivalent circuit model with a resistor in series with a parallel configuration of a second resistor and a capacitor.

eisfom = eisModel("R0+(R1,C1)")

eisfom =
  EISModel with properties:

     CircuitTopology: "R0+(R1,C1)"
       NumParameters: 3
       ParameterList: ["R0"    "R1"    "C1"]
     ParameterValues: [0.0250 0.0035 150]
    CircuitImpedance: "(R0 + ((R1 * (1/(i*w*C1))) / (R1 + (1/(i*w*C1)))))"
       ParameterList: ["R0"    "R1"    "C1"]

Define the frequency points you want to simulate the model at.

freq = logspace(-2,5,100)

Simulate the EIS circuit at these frequencies and plot the frequency response.

[simRealZ, simImagZ] = simulateFrequencyResponse(eisfom,freq);
plot(simRealZ,-simImagZ,linewidth=1.5)
axis equal

Now add a Warburg impedance term to the EIS circuit topology and observe how the frequency response changes.

eisfom.CircuitTopology = "R0 + (R1,C1) + SIW1";

eisfom =

  EISModel with properties:

     CircuitTopology: "R0 + (R1,C1) + SIW1"
       NumParameters: 4
       ParameterList: ["R0"    "R1"    "C1"    "SIW1"]
     ParameterValues: [0.0250 0.0035 150 1.0000e-03]
    CircuitImpedance: "((R0 + ((R1 * (1/(i*w*C1))) / (R1 + (1/(i*w*C1))))) + (SIW1*(w)^(-1/2) - SIW1*i*(w)^(-1/2)))"
       ParameterList: ["R0"    "R1"    "C1"    "SIW1"]

Simulate the circuit and plot the frequency response.

[simRealZ, simImagZ] = simulateFrequencyResponse(eisfom,freq);
plot(simRealZ,-simImagZ,linewidth=1.5)
axis equal

Input Arguments

circuitModel — Equivalent circuit model to simulate in frequency domain

ECM object | EISModel object

Equivalent circuit model to simulate in the frequency domain, specified as an ECM or EISModel object.

frequency — Frequency

scalar | vector

Frequency, specified as a scalar or vector.

Data Types: double

Output Arguments

realImpedance — Real part of circuit impedance

scalar | vector

Real part of the circuit impedance, returned as a scalar or a vector.

Data Types: double

imaginaryImpedance — Imaginary part of circuit impedance

scalar | vector

Imaginary part of the circuit impedance, returned as a scalar or a vector.

Data Types: double

Version History

Introduced in R2025a
