Display and Volume Rendering

2-D and 3-D medical image display, volume rendering

Medical Imaging Toolbox™ provides tools to visualize 2-D and 3-D medical image data. Interactively display medical images in the Medical Image Labeler app, which automatically orients images in the anterior/posterior, left/right, and inferior/superior directions. Use volume rendering to visualize volumes in 3-D using display presets or customized display settings. You can also publish snapshot images and animations. To get started, see Choose Approach for Medical Image Visualization.

Apps

Medical Image LabelerInteractively explore, label, and publish animations of 2-D or 3-D medical image data (Since R2022b)

Functions

expand all

implayView 2-D medical image series in Video Viewer app (Since R2023a)
montageDisplay medical image slices or frames as montage in patient coordinates (Since R2023a)
montageDisplay medical image slices or frames as montage in patient coordinates (Since R2023a)
volshowDisplay medical volume in patient coordinates (Since R2023a)
viewer3dCreate viewer for 3-D image display (Since R2022b)
SurfaceDisplay surface in 3-D viewer (Since R2022b)
sliceViewerBrowse slices of medical image volume in patient coordinates (Since R2023a)
