Waveform Design and Analysis

Pulsed and continuous waveforms, staggered waveforms, variable PRF, matched filtering, ambiguity function, spectrogram

Phased Array System Toolbox™ lets you create narrowband signal waveforms that are radiated by antennas, microphones, sonar transducers, and arrays. Narrowband signals fall into pulsed and continuous types. Waveform types include rectangular, frequency-modulated continuous, phase-coded, and stepped-frequency signals. You can use the pulse waveform library to radiate different type of pulses during a single simulation. In addition, matched filter algorithms are provided to perform coherent processing. The toolbox lets you create and plot ambiguity functions.
