BLF Files

Read and write Vector binary logging format (BLF) files

Use blfread and blfwrite to import and export data from Vector BLF files.

Functions

`blfinfo`	Get information about Vector BLF file
`blfread`	Read data from Vector BLF file
`blfwrite`	Write data to Vector BLF file

Related Information

File Format Limitations
Platform Support

Featured Examples

Decode CAN Data from BLF Files

Import and decode CAN data from BLF files in MATLAB® for analysis. The BLF file used in this example was generated from Vector CANoe™ using the "CAN - General System Configuration (CAN)" sample. This example also uses the CAN database file, PowerTrain_BLF.dbc, provided with the Vector sample configuration.

Open Live Script

Decode J1939 Data from BLF Files

Import and decode J1939 data from BLF files in MATLAB® for analysis.

Open Live Script

Replay J1939 Logged Field Data to a Simulation

Replay J1939 data from a BLF file acquired from a J1939 system in a real-world application, such as a vehicle running in the field.

Open Live Script
