Quaternion

What Is a Quaternion?

Quaternions are vectors used for computing rotations in mechanics, aerospace, computer graphics, vision processing, and other applications. They consist of four elements: three that extend the commonly known imaginary number and one that defines the magnitude of rotation. Quaternions are commonly denoted as:

q=w+xi+yj+zkwherei2=j2=k2=ijk=1

This rotation format requires less computation than a rotation matrix.

Common tasks for using quaternion include:

  • Converting between quaternions, rotation matrices, and direction cosine matrices
  • Performing quaternion math such as norm inverse and rotation
  • Simulating premade six degree-of freedom (6DoF) models built with quaternion math

For details, see MATLAB® and Simulink® that enable you to use quaternions without a deep understanding of the mathematics involved.
