    Hardware Design of a Lane Detection Algorithm | Vision Processing for FPGA, Part 3

    From the series: Vision Processing for FPGA

    The Vision HDL Toolbox™ lane detection example utilizes many innovative techniques to deliver efficient FPGA hardware using HDL Coder™. Learn about hardware implementation techniques such as:

    • Using system knowledge to reduce the amount of computations required in the hardware
    • Designing custom control logic with a MATLAB® function block
    • Computing averages from a stream of data using a rolling window
    • Redundant “ping-pong” memory buffer to keep pace with the incoming data stream

    Published: 14 Sep 2017
